Ingersoll Rand Vane Starters
Ingersoll Rand vane motors are known for their simple, rugged design, ease of maintenance, and legendary durability. They achieve maximum horsepower at speeds as low as 5,000 RPM and require minimal lubrication for extended life. Operating effectively at lower speeds, these motors enhance bearing longevity, reduce the need for planetary gear reduction, and deliver superior torque per pound compared to other displacement motors.
- SS 100 Series
- 150 BM Series
- SS 350 Series
- SS 800 Series
Features/Benefits
- Powerful, revolutionary lube-free vane motor can be used with air or natural gas
- Alloy steel motor components ensure reliability in harsh conditions
- Offset-gear design for rugged power transfer and easy field service
- Class-leading starting torque for engines up to 15 liters
- One starter replaces the 3BM, 5BM and SS175 series
Versatile
- One size fits engines up to 15 liters to lower cost and reduce inventory
- Compact design and flexible mounting for easy fit-up
- Standard and metric pinions fit most manufacturers’ engines
- Overhung pinion and 360° flange design for easy installation
- Dependable accessories including valves, mufflers and deflectors
Features/Benefits
- Powerful 32 HP motor
- The leading mid-range starter design, the standard by which all others are measured
- Simple design ensures rugged dependability and ease of maintenance
- Multiple offset gear ratios: E = 3.46:1; D = 3.94:1
- Backcap ports for injection lubricating
Versatile
- 150BMG sealed for use in air or gas applications
- Offset design for simple mounting
- Inertia and pre-engaged starters available
- Left- and right-hand rotation available
- 4 inlet, 4 exhaust, and 18 drive housing orientations
- 90-150 psi (6.2-10.3 bars) operation
Features/Benefits
- Rugged 36 HP motor on SS350
- Overhung pre-engaged pinion design for fit-up flexibility
- Backcap ports for injection lubricating
Versatile
- Sealed for use in air or gas applications
- Compact, lightweight design makes installation easier
- Left- or right-hand rotation available
- 4 inlet, 4 exhaust, and 12 housing orientations
- 30-150 psi (2.1-10.3 bars) operation
- SAE 01 and SAE03 mounting flanges fit most worldwide manufacturers’ engines
Features/Benefits
- Powerful 75 HP motor
- The leading large-frame starter design, the standard by which all others are measured
- Simple design ensures rugged dependability and ease of maintenance
- Multiple offset gear ratios: B = 2.18:1; C = 2.53:1; D = 3.44:1
- Backcap ports for injection lubricating
Versatile
- All models sealed for use in air or gas applications
- Offset design for simple mounting
- Inertia (SS810) and pre-engaged (SS815, SS825 and SS850) starters available
- 4 inlet, 4 exhaust, and 16 drive housing orientations
- Left- and right-hand rotation available
- 90-150 psi (6.2-10.3 bars) operation
