Masterflex Peristaltic Metering PUmps B/T SEries
Masterflex® B/T Series peristaltic pumps provide the highest flow rates, with maximum flow rates ranging from 0.3 to 42 LPM. The B/T Series pumps are made to last, with heavy-duty motors and robust danger protection.
Features
- Pump designed for continuous-duty biopharma industry applications.
- IP66 rated 316 stainless steel housing for usage in washdown settings
- Pressure sensors and alerts in real time improve process dependability and save up operator time
How the B/T BioPharma Works
The BioPharma pump has a wide flow range of 0.65 to 42 LPM (0.17 to 11.1 GPM) for higher-flow bioprocess applications. The brushless, maintenance-free motor has a speed control accuracy of 0.1%; bidirectional flow and self-priming capabilities allow for smooth, flawless operation.
Ask Now
Features
- Analog communication employed for remote control of voltage, current, and contact closure
- When the door is opened, an interlock switch turns off the power to stop the drive
- Flow rate with B/T tubing ranges from 0.71 to 42 LPM
How the Digital Drive Works
This long-lasting, variable-speed digital drive is perfect for bulk fluid transfer and dispensing applications. It can handle large batches fast and efficiently, with flow rates of up to 42 LPM (11.1 GPM).
Ask Now
Features
- The Rapid-Load® pump head occlusion mechanism moves the occlusion bed out of the way for easier tube loading and better tubing occlusion
- Accepts diameters B/T 87 and B/T 91 of B/T PerfectPositionTM pump tubing
How the Variable Speed Works
Both variable speed and air-powered analog drives are the best option for bulk-transfer applications requiring high flows. With little maintenance, their robust design guarantees a long service life.
Ask Now
Features
- Flow rate 18.9/16 or 42/35 LPM with B/T tubing
- Accepts diameters B/T 87 and B/T 91 of B/T PerfectPositionTM pump tubing
- Interlock switch shuts off power to stop drive when door is opened
How the Fixed Speed Works
The ideal option for high-flow bulk-transfer applications is a Masterflex® B/T Fixed Speed® drive. Their robust design guarantees long service life with little maintenance. A new and improved Rapid-Load® pump head is included with all B/T drives for quick and straightforward tube changes. The increased retention mechanism that the new occlusion offers keeps the tubing firmly in place, significantly streamlining the loading procedure.
Ask Now
Features
- The optimal flow capacity is provided by three rollers with a 5.6:1 hear ratio
- Rotor and roller made of Nylatron® for increased durability and chemical resistance
- Accepts diameters B/T 87 and B/T 91 of B/T PerfectPositionTM pump tubing
How the Rapid Load Works
B/T Rapid-Load pump heads provide for quick and easy tubing replacements, as well as an occlusion mechanism that pulls the tubing occlusion bed out of the way for simple and consistent tube loading. The powder-coated cast aluminum and polycarbonate pump head door is made of strong stainless steel/powder-coated carbon steel, and the rollers are Nylatron® for rigorous dependability.
Ask Now
